Mercury Envy 1500VA/1350W Rackmount and Tower Smart-UPS
Mercury MPM 1.5K RT Rackmount & Tower Convertible Online UPS-UK plug, 0.9PF, 1.5KVA/1.35KW, 1/1 phase, 36Vdc ( 3 x 9AH/12V battery ) 2 x universal output sockets, RS232 & USB Communication,
Mercury Envy Rackmount & Tower Convertible UPS is a reliable alternative power source. It is your perfect backup in the event of a power outage to keep your devices running. When there is a power cut, this UPS automatically switches over with zero downtime. Mercury Envy Rack Mount & Tower Convertible UPS protects your electronic equipment from damage due to power outages, surges, and spikes while providing short-term battery power during an outage. The Mercury Envy Rack Mount & Tower Convertible UPS features Automatic Voltage Regulation (AVR), which instantly adjusts high and low voltage fluctuations to safe levels for your electronics, saving battery power for when you need it most during storms and power outages.
Distinctive Features
Automatic restart of loads after UPS shutdown – Automatically starts up the connected equipment upon the return of utility power. Automatic self-test – Periodic battery self-test ensures early detection of a battery that needs to be replaced. Automatic Voltage Regulation (AVR) – Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment. Resettable circuit breaker – Easy recovery from overloads; no need to replace a fuse.
General specifications
- Mercury Envy Rackmount & Tower Convertible ups
- 1.5KVA/1350W 0.9PF 1/1 Phase
- 36V DC
- 3X9AH /12V Battery
Technical Specifications
Weight | 4.2kg |
Model | Mercury Envy |
Color | Black |
Voltage/Wattage | 220V |
Rated Power | 1.5KVA/1350W |
Other Features | Overload Protection |
Brand | Mercury |
General
PROVIDED EQUIPMENT |
CD with software
Documentation CD Installation guide Rack mounting support rails Smart-UPS signalling RS-232 cable USB cable |
---|
NUMBER OF RACK UNIT |
2U
|
|
---|---|---|
COLOUR |
Black
|
|
DEPTH |
45.7 cm
|
|
HEIGHT |
8.9 cm
|
|
NET WEIGHT |
28.64 kg
|
|
WIDTH |
43.2 cm
|
NETWORK FREQUENCY |
50/60 Hz +/- 3 Hz auto-sensing
|
|
---|---|---|
PLUG STANDARD |
IEC 320 C14
|
|
INPUT VOLTAGE LIMITS |
151…302 V adjustable
160…286 V |
|
INPUTVOLT_OTHER |
220 V
240 V |
|
INPUT VOLTAGE |
230 V
|
RATED POWER IN W |
1000 W
|
|
---|---|---|
MAXIMUM CONFIGURABLE POWER IN W |
1000 W
|
|
HARMONIC DISTORTION |
Less than 5 % at full load
|
|
OUTPUT FREQUENCY |
47…53 Hz for 50 Hz nominal sync to mains
57…63 Hz for 60 Hz nominal sync to mains |
|
OUTPUTVOLT_OTHER |
220 V
240 V |
|
UPS TYPE |
Line interactive
|
|
WAVE TYPE |
Sine wave
|
|
NB OF POWER SOCKET OUTLETS |
4 IEC 320 C13
2 IEC Jumpers |
|
OUTPUT VOLTAGE |
230 V
|
PRODUCT CERTIFICATIONS |
C-Tick
CE TÜV VDE |
|
---|---|---|
STANDARDS |
EN 50091-1
EN 50091-2 |
AMBIENT AIR TEMPERATURE FOR OPERATION |
0…40 °C
|
|
---|---|---|
RELATIVE HUMIDITY |
0…95 %
|
|
OPERATING ALTITUDE |
0…10000 ft
|
|
AMBIENT AIR TEMPERATURE FOR STORAGE |
-15…45 °C
|
|
STORAGE ALTITUDE |
0.00…15240.00 m
|
